High Pressure Energy Saving Low Consumption Jet Dyeing Machine

Name: High Pressure Energy Saving Low Consumption Jet Dyeing Machine
Brand: ALEETEX(CHINA) TECHNOLOGY CO.,LTD
SKU: AS-A
Price: 127,500.00 USD
Availability: InStock

Brand Name:	Alees
Model Number:	AS-A
MOQ:	1
Price:	USD5000-250000
Supply Ability:	50 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Shape:

O Shape

Meterial:

SUS 316L

Voltage:

380V-50HZ

Controller:

SETEX747 / AS9000A(China) / EAS-PCT310

Control System:

Full Automatic

Packaging Details:

Wooden Case/Plastic Film

Supply Ability:

50 sets per month

Highlight:

high pressure overflow dyeing machine

energy saving overflow dyeing machine

Product Description

Introduction

AS-A series is a groundbreaking U-flow dyeing machine designed to transform textile processing with its ultra-low liquor ratio of 1:5-1:6. By integrating an innovative dye circulation system and intelligent fabric handling technology, it achieves exceptional dyeing uniformity while significantly reducing resource consumption. This advanced system cuts additive usage by over 60% and reduces dyestuff requirements by 5%-10% through precise chemical dosing controls. Environmental performance is equally remarkable, with a 60% reduction in wastewater discharge and substantial decreases in water, energy, and steam consumption compared to conventional dyeing systems.

Technical Parameters

-Maximum fabric speed: 350m/min

-Maximum working pressure: Mpa 0.4

-Maximum operating temperature: 135℃

-Heating rate: 25℃-100℃ about 5℃/min

100℃-130℃ about 2.5℃/min

(dry saturated steam pressure at 0.7Mpa)

-Cooling rate: 130-100℃ about 3℃/min

100℃-85℃average2℃/min

(cooling water pressure at 0.3Mpa, cooling water temperature: 5℃~10℃)

-Liquor Ratio: 1:5-1:6

Model and Specifications

Model	Capacity (KG)	Dimension	Main Pump Power (KW)
Model	Capacity (KG)	*LWH (MM)*	Main Pump Power (KW)
AS-A-Mini-25KG	25	280034002900	4
AS-A-Mini-50KG	50	300036003150	4
AS-A-Mini-100KG	100	300037003300	4
AS-A-1T	250-300	390055003750	11
AS-A-2T	500-600	540055003750	18.5
AS-A-3T	750-900	700057203750	30
AS-A-4T	1000-1200	850057503750	37
AS-A-6T	1500-1800	1200057503750	45
