Rapid High Pressure Cheese Dryer Machine High Capacity With Automatic Control

Name: Rapid High Pressure Cheese Dryer Machine High Capacity With Automatic Control
Brand: ALEETEX(CHINA) TECHNOLOGY CO.,LTD
SKU: AS-HP
Price: 127,500.00 USD
Availability: InStock

Brand Name:	Alees
Model Number:	AS-HP
MOQ:	1
Price:	USD5000-250000
Supply Ability:	50 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Shape:

Vertical Type

Meterial:

SUS 316L

Voltage:

380V-50HZ

Controller:

SETEX747 / AS9000A(China) / EAS-PCT310

Control System:

Full Automatic

Packaging Details:

Wooden Case/Plastic Film

Supply Ability:

50 sets per month

Highlight:

Rapid High Pressure Cheese Dryer Machine

Rapid pressure yarn dryer machine

High Capacity pressure yarn dryer machine

Product Description

Introduction

AS-HP is a high-efficiency industrial-grade pressure dryer designed for rapid moisture removal in materials processing. The yarn is placed in a sealed cylinder, and compressed air is injected to a specific pressure. First, most of the moisture in the wet yarn ball is squeezed out. Then, the heated high-temperature and high-pressure air driven by a fan penetrates the yarn, causing the moisture to evaporate and circulate with the compressed air within the closed machine. The moisture is condensed and drained through a cooler until the yarn is completely dried.

Technical Parameters

Max working pressure: 0.5Mpa

Maximum working temperature: 135℃

Drying Time: 45Min(Polyester)/90 Min(Cotton)

Model and Specifications

Model	Main Tank diameter(MM)	Total no. Of spindle	Number Of Layers	Maximum Capacity(KG)	Main Pump Power (KW)	Lifting height (MM)
AS-HP-40	400	3	4	12	4	2900
AS-HP-43	430	4	6	24	5.5	3650
AS-HP-55	500	6	7	42	7.5	4050
AS-HP-65	530	8	7	56	11	4350
AS-HP-65	650	8	9	72	15	5000
AS-HP-85	750	18	7	126	15	4500
AS-HP-105	850	24	7	168	18.5	4600
AS-HP-105	1050	24	9	216	22	5250
AS-HP-110	1100	30	9	270	30	5300
AS-HP-140	1200	46	9	414	37	5400
AS-HP-140	1400	46	10	460	45	5750
AS-HP-170	1500	72	9	648	55	5850
AS-HP-170	1700	72	12	864	75	6750
AS-HP-186	1860	90	12	1080	90	6850
AS-HP-186	1860	90	14	1260	110	7600
AS-HP-200	2000	108	10	1080	90	6400
AS-HP-200	2000	108	12	1296	110	7000
AS-HP-226	2260	134	18	2412	160	9250
AS-HP-256	2560	164	19	3116	220	9650
Standard package yarn diameter: 165-170mm Standard dyeing bobbin length: 165-170mm Spacing of spindles:170mm Weight of per package yarn: approach 1KG.
