Low Consumption Textile Dyeing Machine Low Liquor Ration With Vertical Type Shape

Name: Low Consumption Textile Dyeing Machine Low Liquor Ration With Vertical Type Shape
Brand: ALEETEX(CHINA) TECHNOLOGY CO.,LTD
SKU: AS-241E
Price: 127,500.00 USD
Availability: InStock

Brand Name:	Alees
Model Number:	AS-241E
MOQ:	1
Price:	USD5000-250000
Supply Ability:	50 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Shape:

Vertical Type

Meterial:

SUS 316L

Voltage:

380V-50HZ

Controller:

SETEX747 / AS9000A(China) / EAS-PCT310

Control System:

Full Automatic

Packaging Details:

Wooden Case/Plastic Film

Supply Ability:

50 sets per month

Highlight:

Low Consumption Textile Dyeing Machine

Low Consumption cloth dyeing machine

Low Liquor Ration Textile Dyeing Machine

Product Description

Introduction

The AS241E series is an energy-saving package yarn dyeing machine featuring a 90° flat-plate reversal device, high-efficiency tube heat exchanger, and innovative centrifugal pump design, achieving a low 1:5 liquor ratio. More compact than conventional models, it offers lower bath ratios, reduced energy use and operating costs. Suitable for high-temperature dyeing of polyester/blended yarns and normal-temperature processing of cotton, acrylic and wool yarns.With interchangeable carriers, it handles various materials including nylon yarn, hank yarn, tape cords and loose fibers, providing versatile dyeing solutions for diverse textile applications.

Technical Parameters

-Maximum working pressure: Mpa 0.4

-Maximum operating temperature: 135℃

-Heating rate: 20℃~130℃ average 5℃/min
(dry saturated steam pressure at 0.7Mpa)
-Cooling rate: 130℃~80℃ average 2.5℃/min

(cooling water pressure at 0.3Mpa, cooling water temperature: 5℃~10℃)

-Liquor Ratio: 1:5-1:6
