Low Liquor Ration Energy Saving Hank Yarn Dyeing Machine

Name: Low Liquor Ration Energy Saving Hank Yarn Dyeing Machine
Brand: ALEETEX(CHINA) TECHNOLOGY CO.,LTD
SKU: AS-KS
Price: 127,500.00 USD
Availability: InStock

Brand Name:	Alees
Model Number:	AS-KS
MOQ:	1
Price:	USD5000-250000
Supply Ability:	50 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Meterial:

SUS 316L

Controller:

SETEX747 / AS9000A(China) / EAS-PCT310

Control System:

Full Automatic

Voltage:

380V-50HZ

Packaging Details:

Wooden Case/Plastic Film

Supply Ability:

50 sets per month

Highlight:

380v hank yarn dyeing machine

full automatic hank yarn dyeing machine

Product Description

Introduction

AS-KS is suitable for puffing, refining, bleaching and dyeing cotton, wool, artificial wool, acrylic and blended yarn. It also can be used for pre-treatment and after- treatment. This Special Machine is designed to be low energy,low lift and larger quantity flowing.When working under high temperature,It could keep it’s characteristic. It’s three in one that concludes new model.It has low LR,which save materials and reduce the cost by way of improving its structure.

Technical Parameters

-Design pressure: 0.44Mpa

-Maximum working pressure: 0.4Mpa

-Design temperature: 140℃

-Maximum working temperature: 135℃

-Heating rate: 20℃～130℃about 35 minutes(Saturated vapor pressure:0.7Mpa)

-Cooling rate: 130℃～80℃ about 25 minutes(Cooling water pressure:0.3Mpa)Cooling water temperature:5℃～10℃

-Liquid ratio: 1:6 ～1:10

Model and Specifications

Model	No. Of Arms	Arm Length (mm)	Capacity (KG)	General Power (KW)	Dimension *(LWH)(mm)*
AS-KS-1-650	1	650	5	1.5	200024001700
AS-KS-5-1500	5	1500	50-75	7.5	234038001870
AS-KS-20-1500	20	1500	200-300	30	260038002050
AS-KS-28-1500	28	1500	280-420	37	1012836182650
