Name: Thales Triode Radio Frequency Dryer Automatic Water Cooled 1000W
Brand: ALEETEX(CHINA) TECHNOLOGY CO.,LTD
SKU: AS01-85KW
Price: 127,500.00 USD
Availability: InStock

Brand Name:	Alees
Model Number:	AS01-85KW
MOQ:	1
Price:	USD5000-250000
Supply Ability:	50 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Material:

Stainless Steel

Temperature Range:

50°C - 200°C

Voltage:

220V

Frequency:

50Hz

Power:

1000W

Packaging Details:

Wooden Case/Plastic Film

Supply Ability:

50 sets per month

Highlight:

Automatic Radio Frequency Dryer

Automatic rf dryer for textile industry

Water Cooled Radio Frequency Dryer

Product Description

Introduction

AS01-85KW/170KW is suitable for the drying of yarn packages after dyeing and hydro extraction.

Technical Specification and standards

-Electrical supply voltage: 380V±5%

-Electrical supply Frequency: 50HZ

-Operating frequency: 27.12MHZ±0.6%

-Input power: 142KVA

-Output power: 85KW

-Conveyor belt operating speed: 2.5M/H-107M/H

-Cooling system: Water cooling;air cooling

-Water circulation: 2.5m³/h

-Evaporative capacity: 1.2-1.3kg(water)/kw(RF)h

-Steam Consumption: 20-25kg/h Pressure≥0.4Mpa

-Max product height: 260mm

-Max loading width: 1650mm

-External dimensions: 9m*2.4m(3.1mmax)*3.3m

-weight: 4500kg

Technical Specification and standards

Model	AS01-85KW
Electrical supply voltage	380V±5%
Electrical supply Frequency	50HZ
Operating frequency	27.12MHZ±0.6%
Input power	142KVA
Output power	85KW
Conveyor belt operating speed	2.5M/H-107M/H
Cooling system	Water cooling;air cooling
Water circulation	2.5m³/h
Evaporative capacity	1.2-1.3kg(water)/kw(RF)h
Steam Consumption	20-25kg/h Pressure≥0.4Mpa
Max product height	260mm
Max loading width	1650mm
External dimensions	9m2.4m(3.1mmax)3.3m
weight	4500kg
